Unresolved atomics-related symbols when compiling for Armv5

darltrash · September 30, 2025, 2:22am

I am trying to target a very specific device which uses a very old architecture, specifically, ArmV5TEJL which does not support multithreading or atomics

When compiling something like:

const std = @import("std");

pub fn main() !void {
	std.log.info("true awesomesauce", .{});
}

like this:

zig build-exe -target arm-linux-musl -mcpu=arm926ej_s zigtest.zig

it would blow up like this:

...
error: ld.lld: undefined symbol: __sync_val_compare_and_swap_4
    note: referenced by atomics.zig:173 (/home/nelson/.local/share/zigup/0.15.1/files/lib/compiler_rt/atomics.zig:173)
    note:               .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt_zcu.o:(__atomic_load_4) in archive .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt.a
    note: referenced by atomics.zig:316 (/home/nelson/.local/share/zigup/0.15.1/files/lib/compiler_rt/atomics.zig:316)
    note:               .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt_zcu.o:(__atomic_compare_exchange_4) in archive .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt.a
    note: referenced by atomic.zig:32 (/home/nelson/.local/share/zigup/0.15.1/files/lib/std/atomic.zig:32)
    note:               .cache/zig/tmp/9cc30e5291ef1d8d/zigtest_zcu.o:(Thread.Mutex.FutexImpl.tryLock)
    note: referenced 1 more times
error: ld.lld: undefined symbol: __sync_lock_test_and_set_1
    note: referenced by atomics.zig:204 (/home/nelson/.local/share/zigup/0.15.1/files/lib/compiler_rt/atomics.zig:204)
    note:               .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt_zcu.o:(__atomic_store_1) in archive .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt.a
    note: referenced by atomics.zig:271 (/home/nelson/.local/share/zigup/0.15.1/files/lib/compiler_rt/atomics.zig:271)
    note:               .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt_zcu.o:(__atomic_exchange_1) in archive .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt.a
error: ld.lld: undefined symbol: __sync_lock_test_and_set_2
    note: referenced by atomics.zig:204 (/home/nelson/.local/share/zigup/0.15.1/files/lib/compiler_rt/atomics.zig:204)
    note:               .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt_zcu.o:(__atomic_store_2) in archive .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt.a
    note: referenced by atomics.zig:271 (/home/nelson/.local/share/zigup/0.15.1/files/lib/compiler_rt/atomics.zig:271)
    note:               .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt_zcu.o:(__atomic_exchange_2) in archive .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt.a

any way to circumvent this? i’m trying to get this build to be static but i heard that there’s probably a library i can load up? also, as this device i’m targetting doesn’t even do multithreading… can’t I just NOP all of these?

npc1054657282 · September 30, 2025, 3:20am

The implementation of defaultLog uses a lock. Fortunately, according to the documentation, the implementation of log can be customized.

darltrash · September 30, 2025, 9:38am

This makes sense, but what if I use a library that uses a lock internally? (which seems to be the case for a lot of stuff)

Is there a more general approach I could take?

mbrock · September 30, 2025, 10:03am

Does compiling with -fsingle-threaded help? That should turn locks into noops.

darltrash · September 30, 2025, 10:12am

nope, exact same errors

npc1054657282 · September 30, 2025, 1:03pm

After reading the source code, in single_threaded mode, ordinary mutex does not involve atomic weights.

github.com/ziglang/zig

lib/std/Thread/Mutex.zig

7adb15892



          const SingleThreadedImpl = struct {
              is_locked: bool = false,

              fn tryLock(self: *@This()) bool {
                  if (self.is_locked) return false;
                  self.is_locked = true;
                  return true;
              }

              fn lock(self: *@This()) void {
                  if (!self.tryLock()) {
                      unreachable; // deadlock detected
                  }
              }

              fn unlock(self: *@This()) void {
                  assert(self.is_locked);
                  self.is_locked = false;
              }
          };

The reason for the lock problem of defaultLog is that its stderr_mutex happens to use Recursive Mutex.

github.com/ziglang/zig

lib/std/Progress.zig

7adb15892



              .freebsd,
              .serenity,
              => true,

              else => false,
          };

          /// The primary motivation for recursive mutex here is so that a panic while
          /// stderr mutex is held still dumps the stack trace and other debug
          /// information.
          var stderr_mutex = std.Thread.Mutex.Recursive.init;

          fn copyAtomicStore(dest: []align(@alignOf(usize)) u8, src: []const u8) void {
              assert(dest.len == src.len);
              const chunked_len = dest.len / @sizeOf(usize);
              const dest_chunked: []usize = @as([*]usize, @ptrCast(dest))[0..chunked_len];
              const src_chunked: []align(1) const usize = @as([*]align(1) const usize, @ptrCast(src))[0..chunked_len];
              for (dest_chunked, src_chunked) |*d, s| {
                  @atomicStore(usize, d, s, .monotonic);
              }
              const remainder_start = chunked_len * @sizeOf(usize);

This lock is not handled for single_threaded, so it involves atomicity.

github.com/ziglang/zig

lib/std/Thread/Mutex/Recursive.zig

7adb15892



          /// Acquires the `Mutex`, blocking the current thread while the mutex is
          /// already held by another thread.
          ///
          /// The `Mutex` can be held multiple times by the same thread.
          ///
          /// Once acquired, call `unlock` on the `Mutex` to release it, regardless
          /// of whether the lock was already held by the same thread.
          pub fn lock(r: *Recursive) void {
              const current_thread_id = std.Thread.getCurrentId();
              if (@atomicLoad(std.Thread.Id, &r.thread_id, .unordered) != current_thread_id) {
                  r.mutex.lock();
                  assert(r.lock_count == 0);
                  @atomicStore(std.Thread.Id, &r.thread_id, current_thread_id, .unordered);
              }
              r.lock_count += 1;
          }

I searched the standard library for Mutex.Recursive and found only one implementation, stderr_mutex. Therefore, only the code involving stderr might encounter issues in single_threaded mode. You were just unlucky to have used that particular place for testing. Most code using locks should not be a problem in single_threaded mode.

Additionally, implementing atomic instructions in non-atomic form in single_threaded mode is an accepted proposal, but has not yet been implemented.

darltrash · September 30, 2025, 2:09pm

oh wow! that’s in-depth! so should i just use another logging library? is this a problem unique to the logging library? i guess until the zig team implements the non-atomic instruction stuff

npc1054657282 · September 30, 2025, 2:13pm

I think this is a problem with the standard library. The standard library should have provided an alternative implementation for ‘Mutex. Recursive’ under ‘single_threaded’, but it did not do so. You can propose an issue for this purpose.

darltrash · September 30, 2025, 2:24pm

thank you for the information! this was wildly educative, I made an issue here:

github.com/ziglang/zig

Single threaded build leads to unresolved symbols

opened 02:23PM - 30 Sep 25 UTC

darltrash

bug

### Zig Version 0.15.1 ### Steps to Reproduce and Observed Behavior I am tryi…ng to target a very specific device which uses a very old architecture, specifically, ArmV5TEJL which does not support multithreading or atomics When compiling something like: ```zig const std = @import("std"); pub fn main() !void { std.log.info("true awesomesauce", .{}); } ``` like this: ``` zig build-exe -target arm-linux-musl -mcpu=arm926ej_s zigtest.zig ``` it would blow up like this: ``` ... error: ld.lld: undefined symbol: __sync_val_compare_and_swap_4 note: referenced by atomics.zig:173 (/home/nelson/.local/share/zigup/0.15.1/files/lib/compiler_rt/atomics.zig:173) note: .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt_zcu.o:(__atomic_load_4) in archive .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt.a note: referenced by atomics.zig:316 (/home/nelson/.local/share/zigup/0.15.1/files/lib/compiler_rt/atomics.zig:316) note: .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt_zcu.o:(__atomic_compare_exchange_4) in archive .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt.a note: referenced by atomic.zig:32 (/home/nelson/.local/share/zigup/0.15.1/files/lib/std/atomic.zig:32) note: .cache/zig/tmp/9cc30e5291ef1d8d/zigtest_zcu.o:(Thread.Mutex.FutexImpl.tryLock) note: referenced 1 more times error: ld.lld: undefined symbol: __sync_lock_test_and_set_1 note: referenced by atomics.zig:204 (/home/nelson/.local/share/zigup/0.15.1/files/lib/compiler_rt/atomics.zig:204) note: .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt_zcu.o:(__atomic_store_1) in archive .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt.a note: referenced by atomics.zig:271 (/home/nelson/.local/share/zigup/0.15.1/files/lib/compiler_rt/atomics.zig:271) note: .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt_zcu.o:(__atomic_exchange_1) in archive .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt.a error: ld.lld: undefined symbol: __sync_lock_test_and_set_2 note: referenced by atomics.zig:204 (/home/nelson/.local/share/zigup/0.15.1/files/lib/compiler_rt/atomics.zig:204) note: .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt_zcu.o:(__atomic_store_2) in archive .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt.a note: referenced by atomics.zig:271 (/home/nelson/.local/share/zigup/0.15.1/files/lib/compiler_rt/atomics.zig:271) note: .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt_zcu.o:(__atomic_exchange_2) in archive .cache/zig/o/4a90990682dd11096120b80ccb6e796b/libcompiler_rt.a ``` According to an investigation done by one of the Ziggit users here: https://ziggit.dev/t/unresolved-atomics-related-symbols-when-compiling-for-armv5/12275/7, it's probably related to #1911 and the fact that Mutex.Recursive does not have a single threaded backend. ### Expected Behavior For it to compile properly into a binary I can use

Southporter · September 30, 2025, 2:27pm

Have you tried implementing a custom logging function and using single_threaded? If the standard logging function is the only place this Recursive lock is in place, you could copy the body, remove the problematic code and get around this issue in the meantime.

In your main file:

pub const std_options: std.Options = .{
    .log_fn = customLogFn,
};

darltrash · September 30, 2025, 2:31pm

Seems like I can’t even use the stdout

const std = @import("std");

pub fn main() !void {
    const stdout = std.fs.File.stdout();
    try stdout.writeAll("Test 2!");
}

this snippet yields the exact same errors
