This beats @memset in 0.16.0.
Another vectorization regression thingy?
fn crazy_memset(dst: []u8, value: u8) void {
const UNROLL = std.simd.suggestVectorLength(u8) orelse @sizeOf(usize);
var i: usize = 0;
while (i + UNROLL <= dst.len) : (i += UNROLL) {
const p: *align(1) @Vector(UNROLL, u8) = @ptrCast(dst[i..]);
p.* = @splat(value);
}
while (i < dst.len) : (i += 1) {
dst[i] = value;
}
}
Maybe I’ll create a PR this this in some time.
Looks good to me.
I’ve been trying for the past few hours to beat yours, but failed. My plan was to improve the second part (the byte per byte part), by using intermediary sizes, but the overhead makes it not profitable.
How about a PR?
I wonder if making the simd part memory aligned to a power of two greater or equal to UNROLL would speed it up?
e.g. Another scalar loop at the start, using the minimum of (alignForward of dst.ptr) and dst.len as the bound, then doing the vectorized loop from that aligned address all the way to the last unrollable chunk, then a scalar loop for the remaining part
(this is kinda inspired by what musl does)
One implementation I currently have is this. It is also partly inspired by what musl does. Probably there is still some optimization potential.
For x86, I believe this would be a net loss. There is ample evidence that unaligned loads and stores don’t matter, and doing it this way would result in spending less time inside the most efficient loop, both at the beginning and end. Consider an array that has size n * UNROLL, but is unaligned. Doing it like you suggest, you would need a scalar loop at the beggining and another at end, while doing like @ericlang has shown, the scalar loop is completely avoided.
With function signature fixed:
const std = @import("std");
export fn improved_memset(dest: ?[*]u8, c: u8, len: usize) callconv(.c) ?[*]u8 {
@setRuntimeSafety(false);
const n = std.simd.suggestVectorLength(u8) orelse @sizeOf(usize);
var i: usize = 0;
while (i + n <= len) : (i += n) {
const p: *align(1) @Vector(n, u8) = @ptrCast(dest.?[i..]);
p.* = @splat(c);
}
while (i < len) : (i += 1) {
dest.?[i] = c;
}
return dest;
}
0000000000000000 <improved_memset>:
0: 55 push rbp
1: 48 89 e5 mov rbp,rsp
4: 53 push rbx
5: 50 push rax
6: 48 89 fb mov rbx,rdi
9: 48 83 fa 40 cmp rdx,0x40
d: 73 04 jae 13 <improved_memset+0x13>
f: 31 ff xor edi,edi
11: eb 24 jmp 37 <improved_memset+0x37>
13: 62 f2 7d 48 7a c6 vpbroadcastb zmm0,esi
19: 31 c0 xor eax,eax
1b: 0f 1f 44 00 00 nop DWORD PTR [rax+rax*1+0x0]
20: 62 f1 fe 48 7f 04 03 vmovdqu64 ZMMWORD PTR [rbx+rax*1],zmm0
27: 48 8d 78 40 lea rdi,[rax+0x40]
2b: 48 83 e8 80 sub rax,0xffffffffffffff80
2f: 48 39 d0 cmp rax,rdx
32: 48 89 f8 mov rax,rdi
35: 76 e9 jbe 20 <improved_memset+0x20>
37: 48 29 fa sub rdx,rdi
3a: 76 0f jbe 4b <improved_memset+0x4b>
3c: 48 01 df add rdi,rbx
3f: 40 0f b6 f6 movzx esi,sil
43: c5 f8 77 vzeroupper
46: e8 00 00 00 00 call 4b <improved_memset+0x4b>
4b: 48 89 d8 mov rax,rbx
4e: 48 83 c4 08 add rsp,0x8
52: 5b pop rbx
53: 5d pop rbp
54: c5 f8 77 vzeroupper
57: c3 ret
With the illegal @ptrCast fixed:
const std = @import("std");
export fn improved_memset(dest: ?[*]u8, c: u8, len: usize) callconv(.c) ?[*]u8 {
@setRuntimeSafety(false);
const n = std.simd.suggestVectorLength(u8) orelse @sizeOf(usize);
const splatted: @Vector(n, u8) = @splat(c);
var i: usize = 0;
while (i + n <= len) : (i += n) {
dest.?[i..][0..n].* = splatted;
}
while (i < len) : (i += 1) {
dest.?[i] = c;
}
return dest;
}
(same machine code, except it won’t miscompile under various conditions, and it won’t become a compile error when we make language changes to vectors)
Duff’s Device:
const std = @import("std");
const assert = std.debug.assert;
export fn improved_memset(dest: ?[*]u8, c: u8, len: usize) callconv(.c) ?[*]u8 {
@setRuntimeSafety(false);
const n = std.simd.suggestVectorLength(u8) orelse @sizeOf(usize);
const splatted: @Vector(n, u8) = @splat(c);
var i: usize = 0;
sw: switch (len % n) {
inline 1...n - 1 => |remainder| {
dest.?[i] = c;
i += 1;
continue :sw remainder - 1;
},
0 => {
assert(i <= len);
if (i == len) return dest;
dest.?[i..][0..n].* = splatted;
i += n;
continue :sw 0;
},
else => unreachable,
}
return dest;
}
0000000000000000 <improved_memset>:
0: 55 push rbp
1: 48 89 e5 mov rbp,rsp
4: 89 d1 mov ecx,edx
6: 83 e1 3f and ecx,0x3f
9: 48 89 f8 mov rax,rdi
c: ff 24 cd 00 00 00 00 jmp QWORD PTR [rcx*8+0x0]
13: 31 c9 xor ecx,ecx
15: e9 d7 02 00 00 jmp 2f1 <improved_memset+0x2f1>
1a: 31 c9 xor ecx,ecx
1c: e9 52 01 00 00 jmp 173 <improved_memset+0x173>
21: 31 c9 xor ecx,ecx
23: e9 7c 01 00 00 jmp 1a4 <improved_memset+0x1a4>
28: 31 c9 xor ecx,ecx
2a: e9 9f 01 00 00 jmp 1ce <improved_memset+0x1ce>
2f: 31 c9 xor ecx,ecx
31: e9 28 01 00 00 jmp 15e <improved_memset+0x15e>
36: 31 c9 xor ecx,ecx
38: e9 4b 01 00 00 jmp 188 <improved_memset+0x188>
3d: 31 c9 xor ecx,ecx
3f: e9 05 01 00 00 jmp 149 <improved_memset+0x149>
44: 31 c9 xor ecx,ecx
46: e9 91 01 00 00 jmp 1dc <improved_memset+0x1dc>
4b: 31 c9 xor ecx,ecx
4d: e9 83 01 00 00 jmp 1d5 <improved_memset+0x1d5>
52: 31 c9 xor ecx,ecx
54: e9 bb 01 00 00 jmp 214 <improved_memset+0x214>
59: 31 c9 xor ecx,ecx
5b: e9 83 01 00 00 jmp 1e3 <improved_memset+0x1e3>
60: 31 c9 xor ecx,ecx
62: e9 fa 01 00 00 jmp 261 <improved_memset+0x261>
67: 31 c9 xor ecx,ecx
69: e9 2f 01 00 00 jmp 19d <improved_memset+0x19d>
6e: 31 c9 xor ecx,ecx
70: e9 fa 01 00 00 jmp 26f <improved_memset+0x26f>
75: 31 c9 xor ecx,ecx
77: e9 6e 01 00 00 jmp 1ea <improved_memset+0x1ea>
7c: 31 c9 xor ecx,ecx
7e: e9 fe 00 00 00 jmp 181 <improved_memset+0x181>
83: 31 c9 xor ecx,ecx
85: e9 b1 00 00 00 jmp 13b <improved_memset+0x13b>
8a: 31 c9 xor ecx,ecx
8c: e9 f3 01 00 00 jmp 284 <improved_memset+0x284>
91: 31 c9 xor ecx,ecx
93: e9 e2 00 00 00 jmp 17a <improved_memset+0x17a>
98: 31 c9 xor ecx,ecx
9a: e9 16 02 00 00 jmp 2b5 <improved_memset+0x2b5>
9f: 31 c9 xor ecx,ecx
a1: e9 13 01 00 00 jmp 1b9 <improved_memset+0x1b9>
a6: 31 c9 xor ecx,ecx
a8: e9 80 00 00 00 jmp 12d <improved_memset+0x12d>
ad: 31 c9 xor ecx,ecx
af: e9 c9 01 00 00 jmp 27d <improved_memset+0x27d>
b4: 31 c9 xor ecx,ecx
b6: e9 d7 01 00 00 jmp 292 <improved_memset+0x292>
bb: 31 c9 xor ecx,ecx
bd: e9 60 01 00 00 jmp 222 <improved_memset+0x222>
c2: 31 c9 xor ecx,ecx
c4: e9 60 01 00 00 jmp 229 <improved_memset+0x229>
c9: 31 c9 xor ecx,ecx
cb: e9 f3 01 00 00 jmp 2c3 <improved_memset+0x2c3>
d0: 31 c9 xor ecx,ecx
d2: e9 91 01 00 00 jmp 268 <improved_memset+0x268>
d7: 40 88 30 mov BYTE PTR [rax],sil
da: b9 01 00 00 00 mov ecx,0x1
df: eb 3e jmp 11f <improved_memset+0x11f>
e1: 31 c9 xor ecx,ecx
e3: e9 d4 01 00 00 jmp 2bc <improved_memset+0x2bc>
e8: 31 c9 xor ecx,ecx
ea: e9 b1 01 00 00 jmp 2a0 <improved_memset+0x2a0>
ef: 31 c9 xor ecx,ecx
f1: e9 d4 01 00 00 jmp 2ca <improved_memset+0x2ca>
f6: 31 c9 xor ecx,ecx
f8: e9 fb 00 00 00 jmp 1f8 <improved_memset+0x1f8>
fd: 31 c9 xor ecx,ecx
ff: e9 56 01 00 00 jmp 25a <improved_memset+0x25a>
104: 31 c9 xor ecx,ecx
106: e9 a7 00 00 00 jmp 1b2 <improved_memset+0x1b2>
10b: 31 c9 xor ecx,ecx
10d: e9 33 01 00 00 jmp 245 <improved_memset+0x245>
112: 31 c9 xor ecx,ecx
114: eb 10 jmp 126 <improved_memset+0x126>
116: 31 c9 xor ecx,ecx
118: e9 91 01 00 00 jmp 2ae <improved_memset+0x2ae>
11d: 31 c9 xor ecx,ecx
11f: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
123: 48 ff c1 inc rcx
126: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
12a: 48 ff c1 inc rcx
12d: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
131: 48 ff c1 inc rcx
134: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
138: 48 ff c1 inc rcx
13b: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
13f: 48 ff c1 inc rcx
142: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
146: 48 ff c1 inc rcx
149: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
14d: 48 ff c1 inc rcx
150: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
154: 48 ff c1 inc rcx
157: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
15b: 48 ff c1 inc rcx
15e: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
162: 48 ff c1 inc rcx
165: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
169: 48 ff c1 inc rcx
16c: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
170: 48 ff c1 inc rcx
173: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
177: 48 ff c1 inc rcx
17a: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
17e: 48 ff c1 inc rcx
181: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
185: 48 ff c1 inc rcx
188: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
18c: 48 ff c1 inc rcx
18f: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
193: 48 ff c1 inc rcx
196: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
19a: 48 ff c1 inc rcx
19d: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1a1: 48 ff c1 inc rcx
1a4: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1a8: 48 ff c1 inc rcx
1ab: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1af: 48 ff c1 inc rcx
1b2: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1b6: 48 ff c1 inc rcx
1b9: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1bd: 48 ff c1 inc rcx
1c0: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1c4: 48 ff c1 inc rcx
1c7: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1cb: 48 ff c1 inc rcx
1ce: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1d2: 48 ff c1 inc rcx
1d5: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1d9: 48 ff c1 inc rcx
1dc: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1e0: 48 ff c1 inc rcx
1e3: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1e7: 48 ff c1 inc rcx
1ea: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1ee: 48 ff c1 inc rcx
1f1: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1f5: 48 ff c1 inc rcx
1f8: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
1fc: 48 ff c1 inc rcx
1ff: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
203: 48 ff c1 inc rcx
206: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
20a: 48 ff c1 inc rcx
20d: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
211: 48 ff c1 inc rcx
214: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
218: 48 ff c1 inc rcx
21b: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
21f: 48 ff c1 inc rcx
222: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
226: 48 ff c1 inc rcx
229: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
22d: 48 ff c1 inc rcx
230: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
234: 48 ff c1 inc rcx
237: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
23b: 48 ff c1 inc rcx
23e: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
242: 48 ff c1 inc rcx
245: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
249: 48 ff c1 inc rcx
24c: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
250: 48 ff c1 inc rcx
253: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
257: 48 ff c1 inc rcx
25a: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
25e: 48 ff c1 inc rcx
261: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
265: 48 ff c1 inc rcx
268: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
26c: 48 ff c1 inc rcx
26f: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
273: 48 ff c1 inc rcx
276: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
27a: 48 ff c1 inc rcx
27d: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
281: 48 ff c1 inc rcx
284: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
288: 48 ff c1 inc rcx
28b: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
28f: 48 ff c1 inc rcx
292: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
296: 48 ff c1 inc rcx
299: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
29d: 48 ff c1 inc rcx
2a0: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
2a4: 48 ff c1 inc rcx
2a7: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
2ab: 48 ff c1 inc rcx
2ae: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
2b2: 48 ff c1 inc rcx
2b5: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
2b9: 48 ff c1 inc rcx
2bc: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
2c0: 48 ff c1 inc rcx
2c3: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
2c7: 48 ff c1 inc rcx
2ca: 40 88 34 08 mov BYTE PTR [rax+rcx*1],sil
2ce: 48 ff c1 inc rcx
2d1: eb 1e jmp 2f1 <improved_memset+0x2f1>
2d3: 66 66 66 66 2e 0f 1f data16 data16 data16 cs nop WORD PTR [rax+rax*1+0x0]
2da: 84 00 00 00 00 00
2e0: 62 f2 7d 48 7a c6 vpbroadcastb zmm0,esi
2e6: 62 f1 fe 48 7f 04 08 vmovdqu64 ZMMWORD PTR [rax+rcx*1],zmm0
2ed: 48 83 c1 40 add rcx,0x40
2f1: 48 39 d1 cmp rcx,rdx
2f4: 75 ea jne 2e0 <improved_memset+0x2e0>
2f6: 5d pop rbp
2f7: c5 f8 77 vzeroupper
2fa: c3 ret
2fb: 31 c9 xor ecx,ecx
2fd: e9 3c ff ff ff jmp 23e <improved_memset+0x23e>
302: 31 c9 xor ecx,ecx
304: e9 6d ff ff ff jmp 276 <improved_memset+0x276>
309: 31 c9 xor ecx,ecx
30b: eb 9a jmp 2a7 <improved_memset+0x2a7>
30d: 31 c9 xor ecx,ecx
30f: e9 3f ff ff ff jmp 253 <improved_memset+0x253>
314: 31 c9 xor ecx,ecx
316: e9 70 ff ff ff jmp 28b <improved_memset+0x28b>
31b: 31 c9 xor ecx,ecx
31d: e9 77 ff ff ff jmp 299 <improved_memset+0x299>
322: 31 c9 xor ecx,ecx
324: e9 d6 fe ff ff jmp 1ff <improved_memset+0x1ff>
329: 31 c9 xor ecx,ecx
32b: e9 c1 fe ff ff jmp 1f1 <improved_memset+0x1f1>
330: 31 c9 xor ecx,ecx
332: e9 5f fe ff ff jmp 196 <improved_memset+0x196>
337: 31 c9 xor ecx,ecx
339: e9 f9 fe ff ff jmp 237 <improved_memset+0x237>
33e: 31 c9 xor ecx,ecx
340: e9 7b fe ff ff jmp 1c0 <improved_memset+0x1c0>
345: 31 c9 xor ecx,ecx
347: e9 00 ff ff ff jmp 24c <improved_memset+0x24c>
34c: 31 c9 xor ecx,ecx
34e: e9 ef fd ff ff jmp 142 <improved_memset+0x142>
353: 31 c9 xor ecx,ecx
355: e9 51 fe ff ff jmp 1ab <improved_memset+0x1ab>
35a: 31 c9 xor ecx,ecx
35c: e9 d3 fd ff ff jmp 134 <improved_memset+0x134>
361: 31 c9 xor ecx,ecx
363: e9 c8 fe ff ff jmp 230 <improved_memset+0x230>
368: 31 c9 xor ecx,ecx
36a: e9 9e fe ff ff jmp 20d <improved_memset+0x20d>
36f: 31 c9 xor ecx,ecx
371: e9 90 fe ff ff jmp 206 <improved_memset+0x206>
376: 31 c9 xor ecx,ecx
378: e9 4a fe ff ff jmp 1c7 <improved_memset+0x1c7>
37d: 31 c9 xor ecx,ecx
37f: e9 97 fe ff ff jmp 21b <improved_memset+0x21b>
384: 31 c9 xor ecx,ecx
386: e9 cc fd ff ff jmp 157 <improved_memset+0x157>
38b: 31 c9 xor ecx,ecx
38d: e9 be fd ff ff jmp 150 <improved_memset+0x150>
392: 31 c9 xor ecx,ecx
394: e9 cc fd ff ff jmp 165 <improved_memset+0x165>
399: 31 c9 xor ecx,ecx
39b: e9 ef fd ff ff jmp 18f <improved_memset+0x18f>
3a0: 31 c9 xor ecx,ecx
3a2: e9 c5 fd ff ff jmp 16c <improved_memset+0x16c>
Unfortunately it was not able to jump directly from the switch condition into the inc/mov section. That would have eliminated all those pairs of jmp/xor.
Tracking issue:
I couldn’t get rid of the indirect jump (it really insists on that for a labelled switch), but I got rid of the incs:
export fn improved_memset(dest: ?[*]u8, c: u8, len: usize) callconv(.c) ?[*]u8 {
@setRuntimeSafety(false);
const n = std.simd.suggestVectorLength(u8) orelse @sizeOf(usize);
const splatted: @Vector(n, u8) = @splat(c);
sw: switch (len % n) {
inline 1...n - 1 => |rem| {
dest.?[rem - 1] = c;
continue :sw rem - 1;
},
0 => {},
else => unreachable,
}
var i: usize = len % n;
while (i + n <= len) : (i += n) {
dest.?[i..][0..n].* = splatted;
}
return dest;
}
asm: Compiler Explorer
Edit again:
I disassembled it locally, and the indirect jump looks gone!
zig build-lib memset2.zig -OReleaseFast && objdump -d -M intel libmemset2.a:
0000000000000000 <improved_memset_nn>:
0: 55 push rbp
1: 48 89 e5 mov rbp,rsp
4: 48 89 f8 mov rax,rdi
7: 89 d1 mov ecx,edx
9: 83 e1 1f and ecx,0x1f
c: 89 cf mov edi,ecx
e: ff 24 fd 00 00 00 00 jmp QWORD PTR [rdi*8+0x0]
15: 40 88 30 mov BYTE PTR [rax],sil
18: 40 88 74 08 e2 mov BYTE PTR [rax+rcx*1-0x1e],sil
1d: 40 88 74 08 e3 mov BYTE PTR [rax+rcx*1-0x1d],sil
22: 40 88 74 08 e4 mov BYTE PTR [rax+rcx*1-0x1c],sil
27: 40 88 74 08 e5 mov BYTE PTR [rax+rcx*1-0x1b],sil
2c: 40 88 74 08 e6 mov BYTE PTR [rax+rcx*1-0x1a],sil
31: 40 88 74 08 e7 mov BYTE PTR [rax+rcx*1-0x19],sil
36: 40 88 74 08 e8 mov BYTE PTR [rax+rcx*1-0x18],sil
3b: 40 88 74 08 e9 mov BYTE PTR [rax+rcx*1-0x17],sil
40: 40 88 74 08 ea mov BYTE PTR [rax+rcx*1-0x16],sil
45: 40 88 74 08 eb mov BYTE PTR [rax+rcx*1-0x15],sil
4a: 40 88 74 08 ec mov BYTE PTR [rax+rcx*1-0x14],sil
4f: 40 88 74 08 ed mov BYTE PTR [rax+rcx*1-0x13],sil
54: 40 88 74 08 ee mov BYTE PTR [rax+rcx*1-0x12],sil
59: 40 88 74 08 ef mov BYTE PTR [rax+rcx*1-0x11],sil
5e: 40 88 74 08 f0 mov BYTE PTR [rax+rcx*1-0x10],sil
63: 40 88 74 08 f1 mov BYTE PTR [rax+rcx*1-0xf],sil
68: 40 88 74 08 f2 mov BYTE PTR [rax+rcx*1-0xe],sil
6d: 40 88 74 08 f3 mov BYTE PTR [rax+rcx*1-0xd],sil
72: 40 88 74 08 f4 mov BYTE PTR [rax+rcx*1-0xc],sil
77: 40 88 74 08 f5 mov BYTE PTR [rax+rcx*1-0xb],sil
7c: 40 88 74 08 f6 mov BYTE PTR [rax+rcx*1-0xa],sil
81: 40 88 74 08 f7 mov BYTE PTR [rax+rcx*1-0x9],sil
86: 40 88 74 08 f8 mov BYTE PTR [rax+rcx*1-0x8],sil
8b: 40 88 74 08 f9 mov BYTE PTR [rax+rcx*1-0x7],sil
90: 40 88 74 08 fa mov BYTE PTR [rax+rcx*1-0x6],sil
95: 40 88 74 08 fb mov BYTE PTR [rax+rcx*1-0x5],sil
9a: 40 88 74 08 fc mov BYTE PTR [rax+rcx*1-0x4],sil
9f: 40 88 74 08 fd mov BYTE PTR [rax+rcx*1-0x3],sil
a4: 40 88 74 08 fe mov BYTE PTR [rax+rcx*1-0x2],sil
a9: 40 88 74 08 ff mov BYTE PTR [rax+rcx*1-0x1],sil
ae: 48 83 c9 20 or rcx,0x20
b2: 48 39 d1 cmp rcx,rdx
b5: 77 18 ja cf <improved_memset_nn+0xcf>
b7: c5 f9 6e c6 vmovd xmm0,esi
bb: c4 e2 7d 78 c0 vpbroadcastb ymm0,xmm0
c0: c5 fe 7f 44 08 e0 vmovdqu YMMWORD PTR [rax+rcx*1-0x20],ymm0
c6: 48 83 c1 20 add rcx,0x20
ca: 48 39 d1 cmp rcx,rdx
cd: 76 f1 jbe c0 <improved_memset_nn+0xc0>
cf: 5d pop rbp
d0: c5 f8 77 vzeroupper
d3: c3 ret
I tried to improve on your duff’s device code by changing splatted from a vector to an array and added a couple more switch cases for n/2 and n/4. It seems to result less generated code.
export fn improved_memset3(dest: ?[*]u8, c: u8, len: usize) callconv(.c) ?[*]u8 {
@setRuntimeSafety(false);
const n = std.simd.suggestVectorLength(u8) orelse @sizeOf(usize);
const splatted: [n]u8 = @splat(c);
var d = dest.?;
const end = dest.? + len;
sw: switch (len % n) {
0 => {
if (d == end) return dest;
assert(@intFromPtr(d + n) <= @intFromPtr(end));
d[0..n].* = splatted;
d += n;
continue :sw 0;
},
n / 2 => {
assert(@intFromPtr(d + n / 2) <= @intFromPtr(end));
d[0 .. n / 2].* = splatted[0 .. n / 2].*;
d += n / 2;
continue :sw 0;
},
n / 4 => {
assert(@intFromPtr(d + n / 4) <= @intFromPtr(end));
d[0 .. n / 4].* = splatted[0 .. n / 4].*;
d += n / 4;
continue :sw 0;
},
else => |remainder| {
d[0] = c;
d += 1;
continue :sw remainder - 1;
},
}
return dest;
}
$ zig build-obj -fstrip -OReleaseFast /tmp/tmp.zig -femit-bin=/tmp/tmp.o && objdump -d /tmp/tmp.o
/tmp/tmp.o: file format elf64-x86-64
Disassembly of section .text:
0000000000000000 <improved_memset3>:
0: 55 push %rbp
1: 48 89 e5 mov %rsp,%rbp
4: 48 8d 0c 17 lea (%rdi,%rdx,1),%rcx
8: 83 e2 1f and $0x1f,%edx
b: 48 89 f8 mov %rdi,%rax
e: 48 83 fa 11 cmp $0x11,%rdx
12: 73 0c jae 20 <improved_memset3+0x20>
14: ff 24 d5 00 00 00 00 jmp *0x0(,%rdx,8)
1b: 0f 1f 44 00 00 nopl 0x0(%rax,%rax,1)
20: 49 89 d0 mov %rdx,%r8
23: 40 88 37 mov %sil,(%rdi)
26: 48 ff c7 inc %rdi
29: 48 ff ca dec %rdx
2c: 48 83 fa 11 cmp $0x11,%rdx
30: 73 ee jae 20 <improved_memset3+0x20>
32: 42 ff 24 c5 00 00 00 jmp *0x0(,%r8,8)
39: 00
3a: c5 f9 6e c6 vmovd %esi,%xmm0
3e: c4 e2 79 78 c0 vpbroadcastb %xmm0,%xmm0
43: c5 fa 7f 07 vmovdqu %xmm0,(%rdi)
47: 48 83 c7 10 add $0x10,%rdi
4b: eb 34 jmp 81 <improved_memset3+0x81>
4d: 40 0f b6 d6 movzbl %sil,%edx
51: 49 b8 01 01 01 01 01 movabs $0x101010101010101,%r8
58: 01 01 01
5b: 4c 0f af c2 imul %rdx,%r8
5f: 4c 89 07 mov %r8,(%rdi)
62: 48 83 c7 08 add $0x8,%rdi
66: eb 19 jmp 81 <improved_memset3+0x81>
68: 0f 1f 84 00 00 00 00 nopl 0x0(%rax,%rax,1)
6f: 00
70: c5 f9 6e c6 vmovd %esi,%xmm0
74: c4 e2 7d 78 c0 vpbroadcastb %xmm0,%ymm0
79: c5 fe 7f 07 vmovdqu %ymm0,(%rdi)
7d: 48 83 c7 20 add $0x20,%rdi
81: 48 39 cf cmp %rcx,%rdi
84: 75 ea jne 70 <improved_memset3+0x70>
86: 5d pop %rbp
87: c5 f8 77 vzeroupper
8a: c3 ret
I made a little benchmark script which memsets a 10M - rand() % 1000 length buffer and it seems to be very close to the same speed.
Not sure if this is useful for anything. Just thought I’d share since it partially works around the duff’s device codegen bug. benchmark script if anyone wants to see.
That’s good in that it adds extra vectorisation, which is nice. But it doesn’t unroll the loop at all, so there is a branch after every single write, even for a single byte.
What Duff’s Device does is unroll the loop, so there is only a single branch instruction for the call, instead of one for each write. This can speed up the CPU as is it better able to pipeline the instructions.
What you’ve written isn’t a Duff’s device. The key difference is the use of inline in the switch statement. That’s what forces the loop to be unrolled by generating a distinct code path for each value of the switch. Without it, it reverts to a conventional loop construct, like while or for.
Whether the extra vector writes make up for the loop not being unrolled would have to be benchmarked, although as the only difference is in the final ~1-30 bytes being copied, benchmarking this accurately is harder than it seems. I would be curious if unrolling is even worth it.
Nice catch and thanks for the explanation. Missing inline was an oversight. My benchmark did seem like the vector writes made up for some of the extra branching. I did try to simplify the benchark script but I feel like its still not great with the arg parsing and prng calls.
